Wire-to-Board Connector, 1.25mm Pitch, 1x9P, Vertical SMT, KH-A1252VS-9P-CAP

Wire-to-Board Connector, 1.25mm Pitch, 1x9P, Vertical SMT, KH-A1252VS-9P-CAP

Current Rating: 1A AC/DC
Voltage Rating: 100V AC/DC
Temperature Range: -25°C to +85°C
Contact Resistance: ≤ 30mΩ
Insulation Resistance: ≥ 100MΩ

Inquiry Datasheet

Product Details

Product Features
● 1.25mm pitch, efficient pin count
● 1x9P vertical SMT format
● Surface-mount, compact structure
● Current: 1A AC/DC
● Voltage: 100V AC/DC
● Operating temp: -25°C to +85°C
● Contact resistance ≤ 30mΩ
● Insulation resistance ≥ 100MΩ

Product Benefits
● Suited for small electronic devices
● Simplifies PCB layout routing
● Stable power/signal transmission
● Excellent for miniaturized designs
● Enhances electrical performance in tight spaces

Product Applications
● Signal converters
● Smart sensors
● Surveillance equipment
● DIY electronics
● Interface control boards
