Home -Product -RF Series -RF Connector -BNC -Kinghelm BNC Connector RF Coaxial Connector Diameter 9.5 mm - KH-BNC75-3511
Kinghelm BNC Connector RF Coaxial Connector Diameter 9.5 mm - KH-BNC75-3511 Kinghelm BNC Connector RF Coaxial Connector Diameter 9.5 mm - KH-BNC75-3511 Kinghelm BNC Connector RF Coaxial Connector Diameter 9.5 mm - KH-BNC75-3511
Kinghelm BNC Connector RF Coaxial Connector Diameter 9.5 mm - KH-BNC75-3511

Product Details

Product Description:

The Kinghelm BNC Connector RF Coaxial Connector Diameter 9.5 mm - KH-BNC75-3511 is a high-quality product designed for use in electronic devices that require high-frequency signal transmission. It is commonly used in communication equipment, such as antennas, transmitters, and receivers.


This connector is made of high-quality materials, including a gold-plated brass body and a PTFE insulator, which ensures excellent electrical performance and durability. It is compatible with BNC connectors and can be easily installed on the PCB board.


The KH-BNC75-3511 connector has a frequency range of DC to 4 GHz and a maximum voltage rating of 500V. It also has a low insertion loss and high return loss, which makes it ideal for high-frequency applications.


Overall, the Kinghelm BNC Connector RF Coaxial Connector Diameter 9.5 mm - KH-BNC75-3511 is a reliable and high-performance product that can meet the demands of various electronic devices that require high-frequency signal transmission.


Product Features:

1. BNC connector design for quick and easy installation and removal.

2. High reliability with excellent shock and vibration resistance.

3. Compact size reduces installation space requirements.

4. High-quality material construction ensures long-term stable performance.


Product Parameters:

 Parameters Tables

Brand

 Kinghelm

Model

 KH-BNC75-3511

Connector Type

 BNC Connector

RF Connector Type

 Coaxial Connector

Diameter

 9.5 mm

Operating Temperature Range

 -40℃ ~ +85℃



Application Areas:

Kinghelm BNC Connector RF Coaxial Connector Diameter 9.5mm - KH-BNC75-3511 is suitable for RF signal transmission in various fields, including cable TV, set-top boxes, satellite receivers, car navigation, and other industries.
