Wire to Board Connector, XH Connector, 2.5mm Pitch, 1x6P, KH-XH-6A-W
Current Rating: 3A AC/DC
Voltage Rating: 250V AC/DC
Temperature Range: -25℃ to +85℃
Contact Resistance: 20mΩ Max
Insulation Resistance: 1000MΩ Min
Product Features
● 2.5mm pitch
● 1x6P single row
● Right-angle mounting type
● 3A current rating
● -25℃ to +85℃ operating temperature
● Push-pull locking mechanism
Product Benefits
● Reliable and compact connection
● Space-saving right-angle design
● Easy insertion and removal
● Resistant to heat and vibration
● Simplifies assembly and maintenance
Product Applications
● Portable electronics
● Automotive control modules
● Industrial sensors
● Communication devices
● Medical portable equipment
