Temperature Range: -40°C~125°C
Standard lmpedance: 50Ω
Frequency Range: 0~6Ghz
Medium Pressure Resistance: 750V
Insulation Resistance: 1000MΩ
Product Benefits:
Compact Design: Space-efficient for integration into tight spaces on PCBs.
Reliable Signal Transmission: Ensures minimal signal loss and high performance.
Secure Connection: Provides a stable and durable connection with low risk of disconnection.
Ease of Use: Simple to install and maintain, making it user-friendly.
Product Applications:
Telecommunications: Ideal for connecting antennas and other RF components in communication devices.
Consumer Electronics: Used in devices like radios, TVs, and GPS units.
Networking Equipment: Facilitates connections in routers, modems, and other network devices.
Test Equipment: Suitable for connecting RF test equipment in laboratory settings.
| File Name | Title | Description |
|---|---|---|
| KH-MCX-KE-STM.pdf | KH-MCX-KE-STM | - |
