Characteristic impedance: 50Ω
Rated current: 0-18GHz
Dielectrically withstanding voltage: 1000VRMS
Voltage rating: 335 VRMS
Insulation Resistance:>5000MΩ
Benefits:
Right-Angle Configuration: Saves space and reduces cable strain by allowing connections in tight or constrained areas.
High Compatibility: Suitable for various MCX and MMCX applications, enhancing versatility.
Reliable Signal Integrity: Ensures consistent and clear signal transmission with minimal loss.
Robust Design: Built to withstand physical stress and provide long-term durability.
Applications:
Compact Electronics: Ideal for devices where space is limited, like small wireless gadgets.
Consumer Devices: Used in portable electronics such as handheld radios and GPS units.
Networking Gear: Connects components in tight spaces within networking devices.
Testing Equipment: Facilitates precise RF measurements in laboratory and diagnostic setups.
| File Name | Title | Description |
|---|---|---|
| KH-MCX-K506-Z.pdf | KH-MCX-K506-Z | - |
Support
If you need design/technical support, please let us know and fill inResponse FormWe will get back to you as soon as possible.
Longevity
The Longevity Program is aimed to provide our customers information from time to time about the expected time that our products can be ordered. The NLP is reviewed and updated regularly by our executive Management Team. View ourlongevity programhere.
Interface: Inner pin Connector Type: Header Operating Temperature Range: -55℃~+155℃ Frequency: 18GHz Impedance: 50Ω
Connector Type: Board-End Package: Plugin Number of Ports: 1 Style: Elbow Interface Length/Height: 3.5mm
Insulator:PTFE Hole:(HPb59-1) AU:0.02~004um Unspecified Tolerance: ±1 Compliance:RoHS
Impedance: 50 ohms Rated Current: 0 to 18GHz Voltage Rate: 335VRMS Insulation Resistance: ≥5000MΩ
Connector Type: Board-Mount Interface: Inner Hole Port Quantity: 1 Interface Diameter: 3.5mm Style: Elbow
Brand: Kinghelm Category: RF Coaxial Connector Connector Type: Header Model: KH-MMCX-K511-W Gross Weight: 1.02 grams (g)
Temperature range: -40°C~ 125°C Standard Impedance: 50Ω Frequency Range: 0~6GHz Dielectric Withstanding Voltage: 750V
Connector Type: Board-Mount Interface Type: Female Port Quantity: 1 Interface Diameter: 4.5mm Interface Length/Height: 4.5mm
