Brand: Kinghelm
Category: RF Coaxial Connector
Connector Type: Header
Model: KH-MMCX-K511-W
Gross Weight: 1.02 grams (g)
Benefits:
Right-Angle Design: Ideal for tight spaces and reduces strain on cables.
Versatile Compatibility: Works with both MCX and MMCX connectors for flexible use.
Stable Connection: Provides reliable signal integrity and low loss.
Durable Construction: Built to endure mechanical stress and harsh conditions.
Applications:
Wireless Communication: Connects antennas and RF modules in compact devices.
Consumer Electronics: Used in devices requiring space-saving connections, such as portable radios.
Networking Equipment: Facilitates connections in tight spots within routers and modems.
Test Equipment: Useful in RF testing setups where space is limited.
| File Name | Title | Description |
|---|---|---|
| KH-MMCX-K511-W.pdf | KH-MMCX-K511-W | - |
