Interface: Inner pin
Connector Type: Header
Operating Temperature Range: -55℃~+155℃
Frequency: 18GHz
Impedance: 50Ω
Product Benefits
● High-performance MCX/MMCX connector reliable signal transmission
● Inner pin design enhances connection stability
● Header type easy mounting on PCBs
● Wide operating temperature range -55℃ to +155℃
● Supports frequencies up to 18GHz excellent performance
● 50Ω impedance optimal signal integrity
● Durable construction ensures long-lasting use
Product Application
● Wireless communication systems
● Telecommunications equipment
● Aerospace and defense applications
● Automotive electronics
● Test and measurement devices
● Industrial control systems
● Consumer electronics
| File Name | Title | Description |
|---|---|---|
| KH-MMCX-K510-Z.pdf | KH-MMCX-K510-Z | - |
Support
If you need design/technical support, please let us know and fill inResponse FormWe will get back to you as soon as possible.
Longevity
The Longevity Program is aimed to provide our customers information from time to time about the expected time that our products can be ordered. The NLP is reviewed and updated regularly by our executive Management Team. View ourlongevity programhere.
Characteristic impedance: 50Ω Rated current: 0-18GHz Dielectrically withstanding voltage: 1000VRMS Voltage rating: 335 VRMS Insulation Resistance:>5000MΩ
Connector Type: Board-End Package: Plugin Number of Ports: 1 Style: Elbow Interface Length/Height: 3.5mm
Connector Type: Board-Mount Interface Type: Female Port Quantity: 1 Interface Diameter: 4.5mm Interface Length/Height: 4.5mm
Insulator:PTFE Hole:(HPb59-1) AU:0.02~004um Unspecified Tolerance: ±1 Compliance:RoHS
Impedance: 50 ohms Rated Current: 0 to 18GHz Voltage Rate: 335VRMS Insulation Resistance: ≥5000MΩ
Connector Type: Board-Mount Interface: Inner Hole Port Quantity: 1 Interface Diameter: 3.5mm Style: Elbow
Brand: Kinghelm Category: RF Coaxial Connector Connector Type: Header Model: KH-MMCX-K511-W Gross Weight: 1.02 grams (g)
Temperature range: -40°C~ 125°C Standard Impedance: 50Ω Frequency Range: 0~6GHz Dielectric Withstanding Voltage: 750V
