1.27mm Female Header Connector, 2X6P, 1A, KH-1.27FH-2X6P-H4.3

1.27mm Female Header Connector, 2X6P, 1A, KH-1.27FH-2X6P-H4.3

Current Rating: 1.0A
Insulation Resistance: 1000MΩ Min
Contact Resistance: 20mΩ max
Withstanding Voltage: AC 500V
Operating Temperature: -40°C to +105°C

Inquiry Datasheet

Product Details

Product Benefits
● Dual row 2x6P design
● Compact 1.27mm pitch
● 1.0A rated current
● 500V withstand voltage
● Surface mount solution

Product Application
● Power distribution boards
● Robotics systems
● IoT gateways
● Smart medical devices
● Automotive electronics


Prev：1.27mm Female Header Connector, 1X10P, 1A, KH-1.27FH-1X10P-H4.3
Next：1.27mm Female Header Connector, 1X4P, 1A, KH-1.27FH-1X4P-H4.3
