Wire to Board Connector, XH Connector, 2.5mm Pitch, 1x7P, KH-XH-7A-Z
Current Rating: 3A AC/DC
Voltage Rating: 250V AC/DC
Temperature Range: -25℃ to +85℃
Contact Resistance: 20mΩ Max
Insulation Resistance: 1000MΩ Min
Product Features
● 2.5mm pitch
● 1x7P single row
● Straight mounting type
● 3A current rating
● -25℃ to +85℃ operating temperature
Product Benefits
● Stable and compact connection
● Suitable for 7-pin signal or power lines
● Easy to install on PCB
● Heat- and vibration-resistant
● Efficient assembly process
Product Applications
● Small electronics
● Automotive sensors
● Compact industrial devices
● Communication modules
● Smart home appliances
