2.54mm Pitch Wire-to-Board Connector, 1x11P, SMD, KH-A2504-11AWB

2.54mm Pitch Wire-to-Board Connector, 1x11P, SMD, KH-A2504-11AWB

Current Rating: 3A AC/DC
Voltage Rating: 250V AC/DC
Temperature Range: -25℃ ~ +85℃
Contact Resistance: 20mΩ Max
Insulation Resistance: 1000MΩ Min

Inquiry Datasheet

Product Details

Product Features
● 2.54mm standard pitch
● 11-pin single-row horizontal configuration
● Horizontal SMT design (flat-mounted on PCB)
● Rated 3A current, 250V AC/DC
● Operating temperature: -25℃ to +85℃

Product Benefits
● Low-profile design for height-constrained layouts
● Efficient signal and power transmission
● Compatible with high-density PCB designs
● High insulation and low contact resistance
● SMT-friendly for automated production

Product Application
● Consumer electronics
● Communication interface modules
● Industrial control boards
● Compact power supply units
● Embedded system PCBs
