2mm Pitch Wire-to-Board Connector, 5-Pin 2-Row Straight Pin, KH-A2015-2X05A

2mm Pitch Wire-to-Board Connector, 5-Pin 2-Row Straight Pin, KH-A2015-2X05A

Current Rating: 3A (AC/DC)
Voltage Rating: 250V (AC/DC)
Temperature Range: -25℃ to +85℃
Contact Resistance: ≤ 20 mΩ
Insulation Resistance: ≥ 1000 MΩ

Inquiry Datasheet

Product Details

Product Features
● 2.00mm pitch, 2x5P (10 pins)
● Straight pin header with through-hole design
● Tin-coated brass terminals for strong conductivity
● Dual-row, compact configuration
● High-strength Nylon housing

Product Benefits
● Fits minimalist circuit board designs
● Easy to solder and remove
● Stable in low-current environments
● Delivers clear signal paths
● Environmentally compliant materials

Product Applications
● IoT device mainboards
● Touch control circuits
● Rechargeable battery packs
● Access control devices
● Entry-level electronics projects
