2.54mm Pitch Wire-to-Board Connector, 1x10P, Vertical SMT, KH-A2504-10AB

2.54mm Pitch Wire-to-Board Connector, 1x10P, Vertical SMT, KH-A2504-10AB

Current Rating: 3A AC/DC
Voltage Rating: 250V AC/DC
Temperature Range: -25℃ ~ +85℃
Contact Resistance: 20mΩ Max
Insulation Resistance: 1000MΩ Min

Inquiry Datasheet

Product Details

Product Features
● 2.54mm pitch for standard board spacing
● 10-pin single-row configuration
● Surface mount vertical design
● Rated 3A, 250V AC/DC
● Temperature range: -25℃ to +85℃

Product Benefits
● Saves PCB space with vertical SMT
● Ideal for medium pin-count layouts
● Stable current and signal flow
● Reliable under wide temperature conditions
● Low contact and high insulation resistance

Product Application
● LED modules
● Embedded control boards
● Power management circuits
● Home automation devices
● Signal interface systems
