Wire-to-Board Connector, 2.54mm Pitch, 1x7P, KH-HX2.54-07FGW

Wire-to-Board Connector, 2.54mm Pitch, 1x7P, KH-HX2.54-07FGW

Current Rating: 4A AC/DC
Voltage Rating: 250V AC/DC
Temperature Range: −25°C to +85°C
Contact Resistance: 20mΩ Max
Insulation Resistance: 1000MΩ Min

Inquiry Datasheet

Product Details

Product Features
● 2.54mm pitch
● 1x7P pin structure
● Right-angle mounting
● 7 pins per row
● Current rating: 4A

Product Benefits
● Compact size for tight spaces
● High current capacity
● Wide temperature tolerance
● Low contact resistance
● High insulation resistance

Product Applications
● Consumer electronics
● Automotive electronics
● Industrial devices
● Power supplies

KH-HX2.54-07FGW_00.jpg KH-HX2.54-07FGW_01.jpg KH-HX2.54-07FGW_02.jpg KH-HX2.54-07FGW_03.jpg KH-HX2.54-07FGW_04.jpg KH-HX2.54-07FGW_05.jpg KH-HX2.54-07FGW_06.jpg KH-HX2.54-07FGW_07.jpg KH-HX2.54-07FGW_08.jpg KH-HX2.54-07FGW_09.jpg
