IDC Connector, 2.54mm Pitch, 8-Pin, 2-Row, KH-2.54PH180-2X8P-L8.9
Current Rating: 3A
Insulation Resistance: 5000 MΩ Min
Dielectric Withstanding Voltage: AC 500V
Operating Temperature: -40℃ to +105℃
Insulator Material: PBT
Contact Plating: Gold Flash
Product Benefits
● 2.54mm pitch, 2-row, 8-pin layout
● Gold flash plating for reliable contact
● PBT insulator for high heat resistance
● Easy 180° straight insertion
● Operates from -40℃ to +105℃
Product Application
● IDC connections in embedded systems
● Industrial control interfaces
● Consumer electronics
● Signal and power transmission
