Golden beacon: introduction to SMA RF coaxial connector

Release date:2021-12-28Author source:KinghelmViews:463

    Shenzhen jinhangbiao Electronics Co., LtdFounded in 2007, shenzhenkinghellmelectronco., Ltd. is a national high-tech and dual soft certification enterprise, "senior member unit of China satellite navigation Association", an enterprise with ISO9001 (04617q13625ros) quality management certification system, and is improving iatf16949 automobile quality management system. Its main business is the R & D, production and sales of Beidou satellite navigation and IOT terminal application hardware, and www.bds666.com Com logistics information intelligent system solution.

Well, let's talk to you:SMA RFIntroduction to coaxial connector

SMA RF coaxial connector was designed as an OSM connector by Bendix in the late 1950s. It was one of the most commonly used RF / microwave connectors at that time. Initially, SMA connectors were designed for 0.141 ″ semi-rigid coaxial cables and precision connectors for microwave applications in the military industry, filled with PTFE media.

Under the conditions at that time, due to the small volume and high frequency (the frequency range of semi-hard cable is DC ~ 18GHz; that of flexible cable is DC ~ 12.4ghz), SMA connector was quickly popularized. Even later developed millimeter wave connectors.

The full name of SMA is smallatype. It is a typical microwave high frequency connector. Its highest frequency is 18GHz. It is a widely used coaxial connector with small threaded connection. SMA connector is suitable for connecting RF cable or microstrip line in RF loop of microwave equipment and digital communication system.

SMA series RF coaxial connector is a small RF coaxial connector with threaded connection. Its characteristic impedance is 50 Ω and the frequency range is 0 ~ 18GHz. It has the advantages of wide frequency band, excellent performance, high reliability and long service life.

The above is the relevant content introduction brought to you by the Xiaobian of Shenzhen Golden navigation mark Electronics Co., Ltd. thank you for reading!
