2mm Pitch Wire-to-Board Connector, 1x8P, Straight Pin, KH-A2026-08A

2mm Pitch Wire-to-Board Connector, 1x8P, Straight Pin, KH-A2026-08A

Current Rating: 3A AC/DC
Voltage Rating: 100V AC/DC
Temperature Range: -25℃ to +85℃
Contact Resistance: 20mΩ Max
Insulation Resistance: 1000MΩ Min

Inquiry Datasheet

Product Details

Product Features
● 2.00mm pitch, wire-to-board design
● 1x8P straight pin configuration
● Rated at 3A, 100V AC/DC
● Contact resistance: 20mΩ Max
● Insulation resistance: 1000MΩ Min

Product Benefits
● Stable power and signal transmission
● Compact layout for space-saving
● Reliable performance in varied temperatures
● Easy to mount on PCB
● Safe and durable connection

Product Applications
● LED lighting systems
● Consumer electronics
● Communication devices
● Industrial controls
● DIY electronics
