Wire to Board Connector, 1.25mm Pitch, 1x6P, SMD, KH-A1251WF-06A

Wire to Board Connector, 1.25mm Pitch, 1x6P, SMD, KH-A1251WF-06A

Current Rating: 1A AC/DC
Voltage Rating: 125V AC/DC
Temperature Range: -25℃ to +85℃
Contact Resistance: 20mΩ Max
Insulation Resistance: 100MΩ Min

Inquiry Datasheet

Product Details

Product Features
● 1.25mm fine pitch for compact layouts
● 1x6P single row pin structure
● Right angle surface mount (SMD) design
● Space-efficient and low-profile housing
● Operating temperature: -25℃ to +85℃
● Current rating: 1A per contact

Product Benefits
● Ideal for high-density PCB applications
● Right angle design simplifies horizontal mating
● Supports automated SMT production
● Stable performance in compact and mobile devices
● Reliable operation in varied temperature environments

Product Applications
● Wearable technology
● LED lighting systems
● Compact consumer electronics
● Communication modules
● Smart home control units
