2mm Pitch Wire-to-Board Connector, 1x10P, Straight Pin, KH-A2026-10A

2mm Pitch Wire-to-Board Connector, 1x10P, Straight Pin, KH-A2026-10A

Current Rating: 3A AC/DC
Voltage Rating: 100V AC/DC
Temperature Range: -25℃ to +85℃
Contact Resistance: 20mΩ Max
Insulation Resistance: 1000MΩ Min

Inquiry Datasheet

Product Details

Product Features
● 2.00mm pitch, 1x10P single row
● Vertical through-hole mounting
● Straight pin design for PCB insertion
● Tin-plated brass contacts
● Compatible with PA connector housing

Product Benefits
● Ensures clean vertical connections
● Compact structure for tight PCB layouts
● Reliable pin alignment during assembly
● Ideal for signal and power transfer
● Strong solder retention

Product Applications
● Consumer device interface headers
● Vertical signal transmission lines
● Compact I/O modules
● Development and test boards
● Digital control circuitry
