2mm Pitch Wire-to-Board Connector, 4-Pin 2-Row Angled Pin, KH-A2015-2X04AW

2mm Pitch Wire-to-Board Connector, 4-Pin 2-Row Angled Pin, KH-A2015-2X04AW

Current Rating: 3A (AC/DC)
Voltage Rating: 250V (AC/DC)
Temperature Range: -25°C to +85°C
Contact Resistance: ≤ 20 mΩ
Insulation Resistance: ≥ 1000 MΩ

Inquiry Datasheet

Product Details

Product Features
● 2x4 pin dual row layout
● 8 total pins
● 2.00mm pitch
● Bent pin, through-hole
● Compact size, light weight

Product Benefits
● Ultra-compact design
● Stable connections
● Easy installation
● Ideal for edge connectors

Product Applications
● Signal transmission circuits
● Hobby electronics
● Compact embedded systems
