2.54mm Pitch Wire-to-Board Connector, 1x8P, SMD, KH-A2504-08AWB

2.54mm Pitch Wire-to-Board Connector, 1x8P, SMD, KH-A2504-08AWB

Current Rating: 3A AC/DC
Voltage Rating: 250V AC/DC
Temperature Range: -25℃ ~ +85℃
Contact Resistance: 20mΩ Max
Insulation Resistance: 1000MΩ Min

Inquiry Datasheet

Product Details

Product Features
● 2.54mm pitch spacing
● 8-pin single-row configuration
● Horizontal SMT design (lying flat on PCB)
● Rated 3A current, 250V AC/DC
● Operating temperature: -25℃ to +85℃

Product Benefits
● Compact design for space-constrained applications
● Ideal for smaller boards or devices
● Reliable electrical and mechanical performance
● Easily integrated into automated SMT processes
● Low contact resistance for stable connections

Product Application
● Small electronic devices
● Industrial controls
● Communication equipment
● Power interface modules
● Embedded system boards
