Crimp Terminal Shell, 3.96mm Pitch, 1x7P, KH-VH-7P-ZK

Crimp Terminal Shell, 3.96mm Pitch, 1x7P, KH-VH-7P-ZK

Current Rating: 7A (AC/DC)
Voltage Rating: 250V (AC/DC)
Temperature Range: -25°C to +85°C
Contact Resistance: ≤ 20mΩ
Insulation Resistance: ≥ 1000MΩ
Withstanding Voltage: 1500V AC/ minute

Inquiry Datasheet

Product Details

Product Benefits
● Current rating 7A AC/DC
● High temperature resistance
● Flame retardant material
● Durable nylon66 housing
● RoHS compliant

Product Application
● Home appliances
● Industrial equipment
● LED lighting systems
● Automotive electronics
● Power supplies
