Button And Strip Battery Connector, SMD, KH-12701-2P170

Button And Strip Battery Connector, SMD, KH-12701-2P170

Rated current: 1.0 A
Rated voltage: 12 V
Withstand voltage: 500 V
Contact resistance: 30 mΩ MAX
Insulation resistance: 500 MΩ
Operating temperature: -40°C to +85°C

Inquiry Datasheet

Product Details

Product Benefits
● Space-saving design
● Rated for 12V
● Low contact resistance
● Operates from -40°C to +85°C
● Durable and reliable

Product Application
● Power connections
● Electronics
● Home appliances
● Industrial applications
