Pluggable Terminal Block, 7.62mm pitch, 3 pin, 15A 300V, KH-ZBK300R-3P-7.62G

Pluggable Terminal Block, 7.62mm pitch, 3 pin, 15A 300V, KH-ZBK300R-3P-7.62G

Rated Voltage & Current: 300V, 15A
Insulation Strength: AC 2000V/min
Insulation Resistance: ≥500MΩ at DC 500V
Operating Temperature Range: -40°C to +105°C
Screw Torque Vlaue: 0.4N.m

Inquiry Datasheet

Product Details

Product Features
● Pitch 7.62mm
● 3 positions 1 row configuration
● Rated voltage 300V and current 15A
● Insulation strength AC 2000V/min
● Insulation resistance ≥500MΩ at DC 500V
● Operating temperature range -40°C to +105°C
● Green color for easy identification

Product Benefits
● Safe and stable electrical connections
● High insulation strength for secure operation
● Suitable for wide temperature conditions
● Compact design to save space
● Durable and long-lasting
● Easy installation

Product Application
● Power distribution
● Electrical control systems
● Industrial equipment
● Automation systems
● Home appliances
● Lighting control
