KH-A42002-2X8A
Brand: Kinghelm
model: KH-A42002-2X8A
Product package: Through-hole (Plug-in), P=4.2mm
Packaging method: Bag
Rated current: 7A
Features
- Type: Wire-to-Board Header Connector
- Pitch: 4.2mm
- Mounting type: Through-hole (DIP / Straight insert)
- Rated current: 7A
- Rated voltage: 600V
- Contact material: Brass
- Contact plating: Tin-plated
- Insulator material: PA66 (Nylon 66)
- Flammability rating: UL94V-2
- Operating temperature: -25°C to +85°C
- Color: Transparent
- Board height (Z-axis): 12.8mm
- Base width (Y-axis): 11.4mm
- Packaging: Bag
Advantages
- High current carrying capability up to 7A, suitable for power transmission applications
- 2mm pitch design ensures stable electrical connection and strong mechanical strength
- PA66 housing with UL94V-2 flame retardant for improved safety and durability
- Tin-plated brass contacts provide reliable conductivity and corrosion resistance
- Through-hole mounting ensures strong PCB retention and vibration resistance
- Compact structure with high voltage rating up to 600V for industrial applications
- Cost-effective and suitable for mass production with stable supply chain support
Applications
- Power supply units (PSU)
- Industrial control equipment
- Consumer electronics power connections
- LED lighting systems
- Home appliances (white goods)
- Battery connection modules
- PCB internal power distribution
- Communication and automation devices
