IPEX PCB Connector
Kinghelm IPEX PCB Connectors are designed for high-frequency, high-speed signal transmission, offering excellent electrical performance and mechanical stability. Compact and reliable, they are ideal for wireless communication devices, IoT terminals, and mobile smart devices, supporting 5G, Bluetooth, Wi-Fi, and GPS applications.
KH-1818085-4, IPEX RF Connector, Board-Mount, 1.2mm Female Interface
Frequency：DC~6 GHz
Impedance： 50Ω
IPEX Type：IPEX IV
Dimensions：1.8×1.8×0.85mm
Diameter：1.2mm
KH-252515-G2.1, Mini IPEX RF Switch Connector
Frequency：DC~6 GHz
Impedance： 50Ω
IPEX Type：IPEX II
Dimensions：2.5×2.5×1.5mm
Diameter： 2.1mm
KH-252515-Y2.1, Mini RF Switch Connector
Frequency：DC~6 GHz
Impedance： 50Ω
IPEX Type：IPEX II
Dimensions：2.5×2.5×1.5mm
Diameter： 2.1mm
KH-272716-2.2, RF IPEX Connector
Frequency：DC~6 GHz
Impedance： 50Ω
IPEX Type：IPEX II
Dimensions：2.7×2.7×1.6mm
Diameter：2mm
KH-3030175-G1, IPEX RF Switch Connector
Frequency：DC~6 GHz
Impedance： 50Ω
IPEX Type：IPEX I
Dimensions：3.0×3.0×1.75mm
Diameter： 2.1mm
KH-3030175-Y1, IPEX Connector, 3.0×3.0×1.75mm, 50Ω Impedance
Frequency：DC~6 GHz
Impedance： 50Ω
IPEX Type：IPEX I
Dimensions：3.0×3.0×1.75mm
Diameter： 2.1mm
KH-IPEX-K501-29, Kinghelm IPEX Board-End SMD Mount
Frequency：DC~6 GHz
Impedance： 50Ω
IPEX Type：IPEX I
Diameter：2mm
KH-IPEX3-2020, IPEX RF Connector, 3rd Generation, Board-Mount
Frequency：DC~6 GHz
Impedance： 50Ω
IPEX Type：IPEX III
Diameter：1.4mm
KH-IPEX4-2020, Kinghelm IPEX Connector Receptacle
Frequency：DC~6 GHz
Impedance： 50Ω
IPEX Type：IPEX IV
Diameter：1.5mm
