MMCX PCB Connector
Kinghelm MMCX Connectors feature a compact design with excellent electrical performance, supporting high-speed, high-frequency signal transmission with minimal loss. Ideal for wireless communication devices, smart wearables, vehicle systems, and IoT terminals, their rotating lock design allows easy connection and maintenance while ensuring reliable operation in diverse environments.
KH-MMCX-JE, MMCX Connector, Gold Plated Inline, Male
Frequency：0~6GHz
Impedance：50Ω
Insulation Resistance：≥1000MΩ
KH-MMCX-KE-STM, MCX/MMCX Connector, Board-End, 6GHz, 50Ω
Frequency：0~6GHz
Impedance：50Ω
Contact Resistance：Center ≤ 5.0 mΩ, Outer ≤ 2.5 mΩ
Interface Diameter：3.5mm
KH-MMCX-KWE, MCX/MMCX Connector, Board-Mount
Interface Diameter：3.5mm
KH-MMCX-PBS, MCX/MMCX Connector, Edge-Mount PCB Receptacle
Frequency：0~6GHz
Impedance：50Ω
Contact Resistance：Center ≤ 25 mΩ, Outer ≤ 15 mΩ
Insulation Resistance：≥500MΩ
Interface Diameter：4.5mm
KH-MMCX-Z, Kinghelm MCX/MMCX Connector
Frequency：0~6GHz
Impedance：50Ω
Insulation Resistance：≥1000MΩ
Interface Diameter：3.45mm
