KH-SSMB-JWE
Brand: Kinghelm
Model: KH-SSMB-JWE
Package Type: Through-hole (plug-in)
Packaging Method: Bag packaging
Net Weight: 1.42 g
Features
- SSMB straight male PCB connector (board-end type)
- Inner pin contact design (male / inner pin interface)
- Straight pin (vertical mounting) structure for PCB integration
- 50Ω impedance for stable RF signal transmission
- Wide frequency range up to 0–6GHz
- Compact 2.7mm interface diameter for miniaturized RF designs
- Through-hole (plug-in) PCB mounting
- Low VSWR ≤ 1.2 ensures low signal reflection and high integrity
- High durability up to 500 mating cycles
- Wide operating temperature range: -40°C to +125°C
Advantages
- High-frequency stability: Supports up to 6GHz for RF and microwave systems
- Low signal loss: 50Ω impedance design ensures efficient transmission
- Compact structure: 2.7mm interface enables high-density PCB layouts
- Reliable mechanical performance: Strong plug-in structure for stable mounting
- Excellent electrical characteristics: Low contact resistance improves signal quality
- Industrial-grade durability: Suitable for long-term use in demanding environments
- Strong environmental resistance: Works reliably under extreme temperatures
Applications
- RF communication modules and transceivers
- Wireless devices (WiFi, IoT, GNSS systems)
- RF test and measurement equipment
- Base stations and telecom infrastructure
- Microwave and high-frequency signal systems
- Aerospace and defense electronics
- High-density PCB RF interconnect solutions
