How to Quickly Select Connector Contacts with Correct Interface Type and Polarity for Different Main Devices and Frequency Bands?

Quick Selection Method for Connector Contacts Based on Device and Frequency Band

Connector contacts can be quickly selected by following the three-step process: “Main Device Type → Frequency Range → Interface & Polarity Matching Rules”, while considering high-frequency compatibility and mechanical reliability.

1. Select Interface by Device Type:

• Mobile terminals: MMCX, IPEX
• Base stations and routers: SMA, N-type
• Satellite communication and test equipment: SMP, 2.92 mm
• Automotive terminals: FAKRA preferred, also QMA, TNC

2. Refine by Frequency Band:

• ≤6 GHz (5G Sub-6G): SMA, QMA, MMCX
• 6–40 GHz (Millimeter wave): SMP, 2.92 mm, 3.5 mm
• ≥40 GHz: 1.85 mm, 1.0 mm

3. Polarity Matching Rules:

• Device female (F) pairs with male (M), and vice versa
• For high frequencies, straight connectors preferred (bent connectors ≤0.3 dB insertion loss)
• Maintain consistent polarity for batch devices

4. Selection Verification:

• Confirm interface type (e.g., SMA-J, F)
• Interface frequency ≥ upper limit of application band
• Outdoor/automotive: use connectors with locking mechanisms
• Indoor: micro connectors without locks are acceptable
