Product Q & A

How to solve the problem of wire gauge when the connecting wire is paired with the terminal?

To solve the problem of wire gauge when the connecting wire is paired with the terminal, it is necessary to consider comprehensively from many aspects. The following are specific solutions:

1. Prophase selection
Clear use requirements: according to the actual application scenarios, determine the current, voltage, power and other parameter requirements. For example, for the connection lines of high-power equipment, it is necessary to select a wire gauge that can carry the corresponding current to avoid overheating and safety hazards.
Refer to the equipment specification: View the technical specification of the equipment or terminal to understand its recommend or allowable wire gauge range. Different equipment and terminals have specific requirements for connecting wire gauges due to their different designs and manufacturing processes.
Consider environmental factors: If the connection line needs to work in special environments such as high temperature, low temperature, and humidity, the adaptability of the line gauge to the environment should be considered. For example, in a high-temperature environment, it may be necessary to select a wire gauge with a large wire diameter and good heat dissipation performance to ensure stable performance.

2. Wire gauge matching
Wire diameter matching: Make sure that the wire diameter of the connecting wire matches the aperture or slot size of the terminal. If the wire diameter is too thick, the terminal may not be connected or the terminal may be deformed; if the wire diameter is too thin, the contact may be poor and the electrical performance may be affected.
Conductor material matching: Common conductor materials include copper and aluminum, and different materials have different electrical conductivity and mechanical properties. In general, copper has better conductivity and is suitable for occasions with high electrical performance requirements; aluminum has a lower cost, but requires a larger wire diameter for the same current carrying capacity. Appropriate materials should be selected according to actual needs and cost considerations, and compatibility with terminal materials should be ensured to avoid problems such as electrochemical corrosion.
Insulation material matching: The insulation material of the connecting wire should match the insulation requirements of the terminal to ensure good insulation performance and prevent short circuit and leakage. At the same time, the temperature resistance, wear resistance, corrosion resistance and other properties of insulating materials should also meet the requirements of the use environment.

3. Installation operation
Correct crimping or welding: the use of appropriate crimping tools and processes for crimping operation, to ensure that the crimping force is moderate, so that the connection line and the terminal to form a good electrical connection and mechanical connection. If it is welding, to master the welding temperature and time, to avoid virtual welding or overheating damage to the connection line and terminal.
Check the connection quality: After the installation is completed, use professional tools such as a multimeter to check the continuity and contact resistance of the connection. Ensure that the contact resistance is within the specified range to ensure the stability and efficiency of current transmission. At the same time, check whether there is looseness, deformation and other abnormal conditions between the connecting wire and the terminal.

4. Testing and verification
Electrical performance test: Before actual use, the electrical performance test of the connection line and the terminal, such as withstand voltage test, current carrying capacity test, etc., to verify whether it meets the design requirements.
Reliability test: Through reliability tests such as vibration test and temperature cycle test, the stability and reliability of the connecting wire and terminal under different working conditions are tested to ensure that there will be no wire gauge-related problems during long-term use.
How to do antenna matching?

Here are some common antenna matching methods:

1) Using the matching network
LC matching network: using inductance (L) and capacitance (C) components to form a matching network, such as π-type network, T-type network, L-type network, etc. The impedance characteristics of the antenna are adjusted to match the impedance of the transmission line or device by properly selecting the values of the inductance and capacitance and combining them in series or parallel.
Transmission line transformer matching network: the use of transmission line transformer to achieve impedance transformation, in the balance-unbalanced transformation and different impedance matching application more, the antenna can be unbalanced impedance into a transmission line or equipment to match the balance or unbalanced impedance, commonly used in high frequency and ultra-high frequency band.
Balun matching network: A balun (balun) can convert an unbalanced signal into a balanced signal, or vice versa, while achieving impedance matching. In some antenna systems that require a balanced feed, such as a dipole antenna, a balun can ensure a good match between the antenna and an unbalanced transmission line or device.

2) Adjust the antenna structure
Changing the size of the antenna: by changing the length, diameter, shape and other physical dimensions of the antenna to adjust its impedance. For example, for a 1/4 wavelength vertical antenna, accurately adjusting its length can achieve the best match at the target frequency.
Adding a tuning element: adding a tuning element such as a variable capacitor, a variable inductor, or a varactor diode to the antenna, and adjusting the electrical length of the antenna by changing the parameters of these elements to achieve impedance matching, which can be used to dynamically adjust the antenna to adapt to different operating frequencies or environmental changes.
Changing the antenna material: Choosing different antenna materials will affect the dielectric constant, conductivity and other characteristics of the antenna, thereby affecting the impedance of the antenna. In some special applications, materials with specific electromagnetic properties may be selected to achieve better matching.

3) Based on measurement and simulation
Using a network analyzer: The S11 parameter (reflection coefficient) of the antenna is measured by the network analyzer to evaluate the matching degree between the antenna and the back-end circuit. According to the measurement results, the parameters of the matching network elements or the antenna structure are adjusted until S11 is close to zero to achieve a good match.
Smith chart: Impedance matching design with Smith chart can visually display the change of antenna impedance and the influence of the addition of matching network elements on impedance. By drawing the initial impedance and target impedance of the antenna on the chart, the value and combination of series or parallel L and C elements to be added are determined.
Electromagnetic simulation software: use electromagnetic simulation software such as HFSS, CST, etc., to model and simulate the antenna and matching network, optimize the antenna structure and matching network parameters in the virtual environment, predict the performance and matching effect of the antenna, and reduce the actual debugging workload and cost.

4) Consider environmental factors
Headroom processing: the environment around the antenna has a great impact on its performance, in the design to ensure that there is enough headroom around the antenna, to avoid metal objects, circuit board copper and other close to the antenna, in order to reduce the interference to the antenna impedance.
Installation location optimization: select the appropriate antenna installation location to avoid installing the antenna near large metal objects, strong electromagnetic interference sources, etc. For an antenna in a mobile device, it is also necessary to consider the influence of a human body, a handheld manner, and the like on antenna performance, and perform corresponding optimization during design and debugging.
What are the different types of connectors?

There are many types of connectors, such as circular connectors, rectangular connectors, RF connectors, fiber optic connectors, etc. The following are the applicable scenarios for different types of connectors:

1) Circular connector
Military and aerospace field: It has the characteristics of high reliability and strong environmental resistance, and can maintain stable electrical connections under extreme conditions such as vibration, shock, high temperature, and low temperature, such as aero-engine control systems, missile guidance systems, etc.
Industrial automation field: It can be used to connect various joints, sensors and controllers of industrial robots, as well as various equipment in automated production lines, and can adapt to oil, dust and electromagnetic interference in industrial environments.
Transportation field: In automobiles, trains, ships and other vehicles, it is used to connect engine control systems, on-board electronic equipment, lighting systems, etc., to ensure reliable connections during vehicle driving.

2) Rectangular connector
Computer and peripheral equipment: widely used in the connection between computer motherboards, hard drives, graphics cards, monitors and other devices, with high transmission rate and intensive pin arrangement, can meet the needs of high-speed data transmission and multi-signal transmission.
Communication equipment: such as switches, routers, base stations and other communication equipment between internal boards, as well as equipment and external cable connection, can achieve high-speed data communication and power distribution.
Power electronic equipment: in power distribution cabinets, frequency converters, power modules and other power electronic equipment, used to connect power lines, control lines and signal transmission lines, can withstand larger current and voltage.

3) RF connector
Wireless communication field: used to connect RF components in wireless communication devices such as antennas, RF amplifiers, filters, transceivers, etc., to ensure efficient transmission and low loss of RF signals, such as 5G base stations, mobile phones, walkie-talkies, etc.
Radar and satellite communication field: The connection between the transmitter, receiver and antenna in the radar system, as well as the connection between the radio frequency equipment of the satellite communication ground station, requires high precision, low standing wave ratio and high power capacity.
Test and measurement equipment: in RF test equipment such as network analyzers, spectrum analyzers and other equipment, used to connect the tested parts and test instruments to ensure the accuracy and stability of the test signal.

4) Optical fiber connector
Communication network field: It is an indispensable component in optical fiber communication network. It is used to connect optical fiber patch cords, optical fiber transceivers, optical modules and other equipment to realize efficient transmission of optical signals. It is widely used in long-distance trunk communication, metropolitan area network, access network, etc.
Data center field: In the data center, it is used to connect optical fiber links between servers, storage devices, switches and other equipment to meet the needs of data centers for high-speed and large-capacity data transmission.
Industrial monitoring and automation: In some industrial monitoring and automation systems that are sensitive to electromagnetic interference, such as petrochemical, power monitoring and other fields, optical fiber connectors are used to connect optical fiber sensors, optical fiber gratings and other equipment to achieve signal transmission and control.

5) Audio Video Connector
Home audio-visual system: used to connect TVs, stereos, DVD players, game consoles and other equipment to realize the transmission of audio and video signals. For example, HDMI connectors can transmit high-definition video and multi-channel audio signals at the same time, and RCA connectors are often used to connect Audio and video input and output interfaces of audio equipment and video equipment.
Professional radio, film and television field: in TV stations, film and television production studios and other places, it is used to connect cameras, video recorders, switching stations, mixer and other professional equipment to ensure high-quality audio and video signal transmission and production.
Conference system and stage lighting and sound: In conference rooms, performance stages and other places, it is used to connect projectors, microphones, speakers, lighting controllers and other equipment to achieve audio and video playback and lighting control.
What is the main purpose of the power cable?

In modern life and work, electrical equipment has become an indispensable part of us. Whether it is household appliances, office equipment, or industrial production equipment, they all need electricity to drive and run. And the power connection line, as a bridge of power transmission, its importance is self-evident. So, what is the main purpose of the power cable?

The main purpose of the power connection line, in short, is to establish a connection between the electrical equipment and the power supply to realize the transmission and distribution of electric energy, so as to ensure the normal operation of the equipment. This is the most basic and core function of the power cable. Through the power connection line, electric energy can be smoothly transmitted from the power supply end to the equipment end, providing the required power support for the equipment.

Different types of power cables have different designs, specifications and performance, so they are suitable for different application scenarios and equipment requirements. For example, in the home environment, our common power connection lines are usually the connection lines between the plug and the socket, and they need to meet the safety standards and power requirements of household electricity. In the industrial field, due to the large power of the equipment, the carrying capacity and durability of the power connection line are required to be higher, so it is necessary to select the power connection line with higher specifications and performance.

Choosing a suitable power cable is essential for the stable operation and safety of the equipment. On the one hand, if the specifications and performance of the power connection line do not match the equipment requirements, it may cause poor power transmission and affect the normal operation of the equipment. For example, too thin power connection lines may not be able to carry the current of high-power equipment, resulting in overheating of the line and even causing safety hazards such as fire. On the other hand, the unqualified power connection line may have problems such as damaged insulation layer and poor contact. These problems may cause power leakage or short circuit, which poses a threat to personal safety.

Therefore, when choosing a power cable, we need to consider multiple factors. The first is the power demand of the equipment, which is a key factor in determining the specifications and carrying capacity of the power cable. The second is the use environment. Different environments have different requirements for the durability, water resistance, and corrosion resistance of the power connection line. In addition, we also need to pay attention to the brand and quality of the power cable, and choose reputable and quality-assured brand products, which can greatly reduce the safety risk during use.

It is worth mentioning that with the progress of science and technology and the continuous upgrading of electrical equipment, the power supply cable is also constantly developing and innovating. For example, some power cables with intelligent control function have appeared on the market, which can be remotely controlled and managed through mobile phone APP or remote control, bringing more convenience and comfort to our life.

In summary, the power connection line, as a bridge for power transmission, plays a vital role between electrical equipment and power supply. Choosing a suitable power cable can not only ensure the normal operation of the equipment, but also improve the safety and convenience of use. Therefore, when purchasing and using the power cable, we need to choose carefully to ensure that it matches the equipment needs and the use environment.
What are the differences and characteristics of horizontal polarization and vertical polarization?

Horizontal polarization and vertical polarization are two different polarization modes of electromagnetic waves, which play an important role in the propagation, reception and application of electromagnetic waves. Below, we will discuss in detail the differences and characteristics of these two polarization methods to help readers better understand the concept and application of electromagnetic wave polarization.

First, from the point of view of difference, the main difference between horizontal polarization and vertical polarization lies in the vibration direction of the electric field vector. In horizontal polarization, the direction of the electric field intensity is parallel to the ground, and the electric field vector vibrates in the horizontal direction. This polarization is usually used for television signals, microwave communications and other occasions. In vertical polarization, the direction of the electric field strength is perpendicular to the ground, and the electric field vector vibrates in the vertical direction. This polarization is widely used in mobile communications, satellite communications and other fields.

Next, we explore the characteristics of horizontal polarization and vertical polarization respectively.

The characteristics of horizontal polarization mainly include:

Good anti-interference: Because the horizontally polarized electric field vector vibrates in the horizontal direction, it is easier to avoid obstacles and interference sources on the ground, thus having better anti-interference performance. This makes horizontal polarization widely used in microwave communication, television signal transmission and other occasions.
Ground reflection has little effect: during the propagation of horizontally polarized electromagnetic waves, the electric field vector is parallel to the ground, so the ground reflection has little effect on it. This helps to reduce the loss and distortion of the signal in the propagation process and improve the communication quality.
Difficult to receive: However, horizontal polarization also presents some challenges. Since the electric field vector vibrates in the horizontal direction, it is necessary to ensure that the polarization mode of the receiving antenna matches the polarization mode of the transmitting antenna during reception. This increases the difficulty and complexity of the reception. At the same time, in some situations, such as urban areas with dense buildings, horizontally polarized electromagnetic waves may be more likely to be blocked and interfered by obstacles such as buildings.
In contrast, the characteristics of vertical polarization include:

Reception is simple: vertically polarized electromagnetic waves are easier to receive. Since the electric field vector is perpendicular to the ground, the receiving antenna can be more easily matched to the polarization pattern of the transmitting antenna. This makes vertical polarization widely used in mobile communications, satellite communications and other fields.
Suitable for mobile reception: vertical polarization is more suitable for mobile reception scenarios. In mobile communications, since user equipment (such as a mobile phone, a tablet computer, etc.) usually has a vertically polarized antenna, a communication connection can be more effectively established with these equipment by using a vertically polarized electromagnetic wave.
Strong ability to penetrate buildings: vertically polarized electromagnetic waves have a stronger ability to penetrate obstacles such as buildings. This helps to ensure that good communication quality is maintained inside buildings or in dense urban areas. However, it should be noted that in some specific situations, such as when there are a large number of metal structures or electromagnetic shielding materials inside the building, the vertically polarized electromagnetic waves may also be affected to a certain extent.
In the communication system, it is very important to choose the appropriate polarization mode to improve the communication quality and stability. Horizontal polarization and vertical polarization have their own unique advantages and applicable scenarios. In practical applications, we need to consider and select the appropriate polarization mode according to the specific communication requirements, environmental conditions and equipment performance and other factors.

For example, in microwave communication, horizontal polarization is usually selected due to the need to avoid ground reflection and obstacle interference. However, in mobile communications, since it is necessary to ensure that a good communication connection is established with the mobile device, and considering that a polarized antenna of the mobile device usually has a vertical directivity, a vertical polarization manner is usually selected.

In addition, with the continuous development of wireless communication technology, more and more new technologies and new applications are emerging. The requirements of these new technologies and applications for electromagnetic wave polarization are constantly changing and upgrading. Therefore, we need to pay close attention to the recent dynamics and development trends of wireless communication technology in order to understand and grasp the recent application and technological progress of electromagnetic wave polarization in time.

In short, horizontal polarization and vertical polarization are the two basic polarization modes of electromagnetic waves. They have a wide range of applications and important roles in communications, radar, satellite transmission and other fields. By understanding the differences and characteristics of these two polarization modes, we can better understand and apply the concept and technology of electromagnetic wave polarization, and provide a strong guarantee for the performance and stability of wireless communication systems. At the same time, we also need to pay close attention to the recent dynamics and development trends of wireless communication technology in order to continuously adapt to and meet the needs of new technologies and new applications for electromagnetic wave polarization.
How does the gain of the antenna affect the signal transmission?

Antenna gain is a measure of the antenna's ability to concentrate on the input power, and its size has an important impact on signal transmission in terms of transmission distance, signal strength, and anti-interference ability, as follows:

1) Transmission distance
High gain extends the transmission distance: the higher the gain, the more concentrated the signal energy emitted by the antenna is in a particular direction, in which the signal propagates farther. For example, in long-distance wireless communication, a high-gain directional antenna can transmit a signal to a place of tens of kilometers or even farther, and is often used for communication between a base station and a base station, and between a base station and a terminal device in a remote area.
Low gain limit transmission distance: low gain antenna signal energy dispersion, in the process of propagation, the signal strength decays faster with distance, the transmission distance is relatively short. For example, if a wireless router used indoors uses a low-gain omnidirectional antenna, its signal coverage may only be within tens of meters.

2) Signal strength and quality
High gain to enhance signal strength: High gain antennas can significantly enhance the signal strength received at the receiving end. In mobile phone communication, when the mobile phone is in a weak signal area, the high-gain mobile phone antenna can better receive the base station signal, so that the number of signals displayed by the mobile phone increases, and the call quality and data transmission speed are improved.
Low gain leads to weak signal: Low gain antennas cannot effectively collect and enhance the signal, which will reduce the received signal strength and deteriorate the signal quality. For example, in a wireless monitoring device using a low-gain antenna, image blur, stuck, or even signal interruption may occur.

3) Anti-interference ability
High gain to enhance the anti-interference: high gain directional antenna by focusing the signal energy in a specific direction, so that the main lobe direction of the signal is stronger, while the side lobe and back lobe are relatively small, reducing the impact of interference signals in other directions. In a complex electromagnetic environment, such as a wireless communication system in a city, a high-gain directional antenna can receive the target signal more accurately, suppress interference signals from other directions, and improve the reliability and stability of communication.
Low gain is susceptible to interference: low gain antenna due to signal energy dispersion, directionality is not obvious, while receiving useful signals, it is easier to receive interference signals from all directions, resulting in signal quality degradation. For example, in an environment where multiple wireless signal sources exist, a device using a low-gain omni-directional antenna may frequently experience signal fluctuations, data transmission errors, and the like.

4) Coverage and angle
High gain reduces coverage angle: For directional antennas, the higher the gain, the narrower the beam width, and the signal is concentrated in a narrower angle range. Although the signal strength and transmission distance increase in the direction of the main lobe, the coverage angle range becomes smaller. For example, the high-gain parabolic antenna used in satellite communication may have a beam width of only a few degrees, which can only cover a small area in a specific direction, but can communicate accurately with the satellite at a long distance.
A low gain increases a coverage angle: although signal strength in each direction is relatively weak, a low-gain omnidirectional antenna can provide 360-degree omnidirectional coverage, which is suitable for a scenario in which a signal needs to be received or sent in a relatively large angle range, for example, in an indoor wireless local area network, the low-gain omnidirectional antenna can provide signal coverage for terminal devices in each direction.
What are the main performance indicators of RF antennas?

The main performance indicators of the RF antenna are as follows:

1) Frequency characteristics
Operating frequency: The center frequency or frequency range at which the antenna is designed to operate determines the type of signal that the antenna can effectively transmit or receive. For example, the antenna operating frequency of the GSM900 system is about 900MHz.
Bandwidth: Indicates the frequency range over which the antenna can operate effectively. The wider the bandwidth, the wider the signal range that the antenna can handle, which can be divided into relative bandwidth, octave bandwidth, etc.

2) Gain and directivity
Gain: Describes the ability of an antenna to amplify a signal, usually expressed in dBi (isotropic) or dBd (dipole). The higher the gain, the farther the signal is transmitted and the greater the signal strength.
Directivity: The directional characteristics of the antenna transmitting or receiving signals. Omnidirectional antennas transmit signals uniformly in all directions and are suitable for scenarios that require omnidirectional coverage; directional antennas transmit signals in a specific direction, such as parabolic antennas, which are commonly used in point-to-point communications or scenarios that require coverage in a specific direction.
Beam width: refers to the width of the main lobe of the antenna, generally refers to the angle between two points where the radiation intensity is reduced by 3dB on both sides of the maximum radiation direction of the main lobe. The smaller the beam width, the better the directional selectivity and the stronger the anti-interference ability, but the coverage will also be reduced.
Front-to-rear ratio: For directional antennas, the front-to-rear ratio measures the gain difference between the antenna in the forward and backward directions. The larger the front-to-rear ratio, the better the directivity of the antenna and the smaller the signal transmission interference.

3) Impedance and standing wave
Input impedance: The impedance of the antenna port, which is usually expected to match the characteristic impedance of the transmission line to reduce reflection, and the input impedance of the general mobile communication antenna is 50Ω.
Standing Wave Ratio (VSWR): A measure of the degree of impedance matching between the antenna and the feed line. The closer the VSWR is to 1:1, the better the impedance matching and the higher the energy transfer efficiency.

1)polarization characteristics
Describe the direction of the electric field of the electromagnetic wave transmitted or received by the antenna. The common polarization types are vertical polarization, horizontal polarization, circular polarization and elliptical polarization. The transmit and receive antennas should have the same polarization for best performance.

5) Radiation and efficiency
Radiation mode: Describes the spatial distribution of the antenna radiation field, which may have different radiation modes such as single mode, dual mode or multi mode.
Efficiency: represents the ratio of the actual radiated power of the antenna to the input power, which reflects the ability of the antenna to convert the input electrical energy into radiated power. The higher the efficiency, the better the antenna performance.
Side lobe suppression: In addition to the main lobe, the smaller the side lobes (side lobes) of the antenna, the better, because larger side lobes will increase the possibility of interference and reduce signal quality.

6) Other indicators
Size: The actual physical size of the antenna, which affects the frequency response, gain, and other performance metrics of the antenna, is an important consideration in some applications with high space requirements.
Isolation: For dual-polarized antennas or multi-antenna systems, isolation refers to the degree of signal isolation between different polarizations or different antennas. The higher the isolation, the smaller the mutual interference between signals.
