FPC Connector, 1mm Pitch, 4P, KH-FPC1.0-H2.0SMT-4P-QCHF
Current Rating: 0.5A/PIN
Voltage Rating: 50V (AC/DC)
Insulation Resistance: 500MΩ Min
Contact resistance: Initial value 30MΩ Max.
Operating Temperature: -40°C ~ +85°C
Product Features
●Fine pitch of 1.0mm for dense layouts
●12-pin configuration for versatile use
●H2.0 SMT compatible for automated assembly
●QCHF design for robust connection
●Kinghelm quality for reliable performance
Product Benefits
●Maximizes space efficiency in devices
●Supports multiple signal types
●Simplifies manufacturing processes
●Ensures stable and secure connections
●Built to last with superior materials
Product Application
●Perfect for smartphones and tablets
●Ideal for portable gaming devices
●Utilized in wearable technology
●Suitable for automotive infotainment systems
●Often seen in high-end consumer electronics
Name
Title
Description
Datasheet
Support
Support
If you need design/technical support, please let us know and fill inResponse FormWe will get back to you as soon as possible.
Longevity
The Longevity Program is aimed to provide our customers information from time to time about the expected time that our products can be ordered. The NLP is reviewed and updated regularly by our executive Management Team. View ourlongevity programhere.
