FPC Connector, 1mm Pitch, 4P, KH-FPC1.0-H2.0SMT-4P-QCHF
Current Rating: 0.5A/PIN
Voltage Rating: 50V (AC/DC)
Insulation Resistance: 500MΩ Min
Contact resistance: Initial value 30MΩ Max.
Operating Temperature: -40°C ~ +85°C
Product Features
●Designed for FPC
●1.0mm pitch with 16-pin configuration
●H2.0 SMT (Surface Mount Technology)
●Front-insert, rear-flip design
●QCHF structure for stability
Product Benefits
●High-density connections save space
●Ensures stable electrical signals
●Facilitates automated SMT production
●Adaptable design for various layouts
●Made from quality materials for durability
Product Application
●Ideal for smartphones and tablets
●Perfect for wearable tech and automotive
●Used in medical and industrial controls
●Suitable for compact electronic devices
●Meets high demands for signal quality and reliability
Name
Title
Description
Datasheet
Support
Support
If you need design/technical support, please let us know and fill inResponse FormWe will get back to you as soon as possible.
Longevity
The Longevity Program is aimed to provide our customers information from time to time about the expected time that our products can be ordered. The NLP is reviewed and updated regularly by our executive Management Team. View ourlongevity programhere.
