FPC Connector, 1mm Pitch, 6P, KH-FPC1.0-H2.0SMT-6P-QCHF
Current Rating: 0.5A/PIN
Voltage Rating: 50V (AC/DC)
Insulation Resistance: 500MΩ Min
Contact resistance: Initial value 30MΩ Max.
Operating Temperature: -40°C ~ +85°C
Product Features
●1.0mm pitch for high-density connections
●24PIN configuration for efficient signal transmission
●H2.0 standard for surface mount technology
●Front insert reverse flipping for optimal space usage
●QCHF design for enhanced stability and reliability
Product Benefits
●Compact design saves valuable PCB space
●Reliable connections minimize signal degradation
●Simplifies assembly for improved production efficiency
●Flexible layout options accommodate various designs
●Durable materials ensure long-term reliability
Product Application
●Ideal for smartphones that require compact connections
●Suitable for tablets where space is limited
●Commonly used in medical devices for high integrity
●Perfect for wearable tech like smartwatches
●Widely applied in automotive control systems for dependable links
Name
Title
Description
Datasheet
Support
Support
If you need design/technical support, please let us know and fill inResponse FormWe will get back to you as soon as possible.
Longevity
The Longevity Program is aimed to provide our customers information from time to time about the expected time that our products can be ordered. The NLP is reviewed and updated regularly by our executive Management Team. View ourlongevity programhere.
