Which design, manufacturing, or environmental factors significantly affect antenna performance parameters and cause deviations from design values?

Among design, manufacturing, and environmental factors, design deviations, manufacturing tolerances, and environmental interference are the primary reasons for discrepancies between actual antenna performance and design specifications.

Design factors

1. Errors in the size or shape of the radiating element directly affect resonant frequency and impedance matching.
2. Feed point displacement from the optimal position causes input impedance shift, reducing energy transfer efficiency.
3. Improper ground structure design impacts antenna directivity and interference rejection.
4. Layout conflicts with other internal components (e.g., battery, ICs) can introduce electromagnetic interference.
5. Insufficient spacing between antenna and nearby metal parts leads to reduced efficiency and severe distortion of radiation patterns.

Manufacturing factors

1. Component machining tolerances exceeding specifications, such as radiating element dimensions or dielectric substrate thickness deviations.
2. Soldering defects, including cold joints or improperly sized solder balls, altering high-frequency distributed parameters.
3. Poor plating quality, uneven thickness, or insufficient coverage affecting surface resistivity.
4. Assembly deviations, such as antenna misalignment or excessive cable bending, increasing impedance variation and VSWR.
5. Material composition differences between actual and specified materials, leading to increased losses, impedance drift, and performance variation.

Environmental factors

1. Temperature and humidity changes can shift dielectric properties, causing resonant frequency drift.
2. Proximity of metal objects or the human body can absorb electromagnetic energy or alter impedance, reducing radiation efficiency.
3. Outdoor environments with salt spray or dust can corrode antenna structures and conductive components.
4. Strong electromagnetic interference (EMI) from industrial equipment or dense base station environments affects signal stability.
