What Should Be Considered When Selecting Antenna Connector Contacts for High-Frequency Applications?

In high-frequency applications, the core goal of selecting antenna connector contacts is to ensure signal integrity and minimize transmission loss, while also maintaining stability and environmental adaptability. Key points to consider include:

1. Electrical Performance:

• Low contact resistance (≤10 mΩ), with gold plating preferred
• Impedance matching (50 Ω, 75 Ω)
• Frequency coverage suitable for the application
• Shielding isolation ≥40 dB

2. Mechanical Reliability:

• Mating cycles ≥1000
• High-elasticity contact springs
• Reliable locking mechanisms, such as threaded or double-latch locks
• Reinforced pins and pressure-resistant housings

3. Environmental Adaptability:

• For harsh environments: IP67+ rating, salt spray resistance ≥72 hours, operating temperature -40°C to 85°C
• Avoid pure tin plating in demanding conditions

4. Selection Guidelines:

• Prefer mature connector types like SMA, MMCX, SMP
• Check insertion loss, VSWR ≤1.3, and other relevant parameters
